spec-kit-extension-wireframe

Spec-Driven Development catches logic errors. It doesn't catch "this doesn't look right."

By the time you've planned, tasked, and started implementing, you're painting a picture you never approved. This extension adds the visual sign-off step SDD is missing: generate wireframes from the spec, iterate on them, sign them off — and then /speckit.plan, /speckit.tasks, and /speckit.implement automatically honor what you approved.

👉 See it live: https://tortoisewolfe.github.io/spec-kit-extension-wireframe/

How it works

Spec-Driven Development already treats spec.md as the source of truth — every downstream command (/speckit.plan, /speckit.tasks, /speckit.implement) reloads it as constraint context. This extension piggybacks on that: on sign-off, approved wireframe paths get written into spec.md under a ## UI Mockup section. From that moment, the visual becomes part of the spec. No changes to core Spec Kit required.

/speckit.specify
     ↓
/speckit.clarify
     ↓
/speckit.wireframe.generate  ← NEW: SVG mockups from spec
     ↓
/speckit.wireframe.review    ← NEW: review + sign-off writes paths into spec.md
     ↓
/speckit.plan                 (reads spec.md → honors wireframes)
     ↓
/speckit.tasks                (reads spec.md → honors wireframes)
     ↓
/speckit.implement            (reads spec.md → honors wireframes)
     ↓
/speckit.wireframe.screenshots ← NEW: regression check vs signed-off wireframes

Installation

Via catalog (once spec-kit#2262 merges)

specify extension add wireframe

Local development

git clone https://github.com/TortoiseWolfe/spec-kit-extension-wireframe
cd /path/to/your/speckit-project
specify extension add --dev /path/to/spec-kit-extension-wireframe

Verify:

specify extension list
# ✓ Wireframe Visual Feedback Loop (v0.1.0)
#   Commands: 5 | Hooks: 3 | Status: Enabled

Commands

Command	Purpose
/speckit.wireframe.prep	Load spec + rules context before generating
/speckit.wireframe.generate	Create SVG wireframes from spec.md (light/dark/both themes)
/speckit.wireframe.review	Review wireframes, classify issues, sign off into spec.md
/speckit.wireframe.inspect	Cross-SVG consistency check
/speckit.wireframe.screenshots	Capture standardized PNGs (Tier-2, needs Python or Docker)

Hooks

The extension registers three optional hooks into SpecKit's workflow:

Hook	Prompts	What it offers
after_specify	"Generate wireframes for this feature now?"	Runs wireframe.generate right after spec creation
before_plan	"Review and sign off wireframes before planning?"	Ensures wireframes are signed off before /speckit.plan locks in the implementation plan
after_implement	"Capture implementation screenshots and compare?"	Regression check: captures the built UI and compares against signed-off wireframes

All hooks are optional — the extension prompts before executing, and you can decline to continue the SpecKit workflow unchanged.

Theme convention

The extension ships two canonical templates in templates/:

• Light theme (light-theme.svg) — parchment/tan canvas for frontend features (UI screens, forms, dashboards)
• Dark theme (dark-theme.svg) — charcoal/slate canvas for backend features (architecture diagrams, RLS policies, OAuth flows, API contracts)

The generator auto-classifies each User Story from spec.md as frontend (UI-describing narrative) or backend (system-describing narrative). Features that mix both → one wireframe per theme.

Override auto-detection with --theme {light|dark|both}.

Theme tokens are documented in templates/THEME-CONVENTION.md.

Configuration

Copy config-template.yml to .specify/extensions/wireframe/wireframe-config.yml and customize. All settings are optional. Common overrides:

themes:
  frontend: "light"   # default
  backend: "dark"     # default
  hybrid: "both"      # default

output:
  svg_dir: "specs/{feature}/wireframes"  # where SVGs land

validator:
  enabled: false      # set true if you install the optional Python validator

Tiers

The extension is designed with progressive enhancement:

• Tier 1 (zero deps): generate, prep, review, inspect — AI does all the work via reading SVG source + reasoning. Works on any machine.
• Tier 2 (optional): screenshots and a validator script use Python (playwright + cairosvg) or Docker for standardized PNG capture and mechanical validation. When unavailable, commands gracefully degrade with an informational message — they don't fail.

You can use this extension with just Tier 1 — everything core works. Tier 2 adds richer visual review and regression checking when you want it.

Example: full loop

Scratch SpecKit project:

specify init my-demo
cd my-demo
specify extension add wireframe

Then in your agent:

/speckit.specify   "User login page with email and password, shows error on invalid credentials"
  → creates specs/001-user-login/spec.md

after_specify hook: "Generate wireframes for this feature now?" → y
  → runs /speckit.wireframe.generate 001
  → auto-classifies as frontend → generates light-theme SVG
  → writes specs/001-user-login/wireframes/01-login.svg

/speckit.wireframe.review 001
  → analyzes SVG, reports: PASS
  → prompts sign-off → y
  → updates specs/001-user-login/spec.md with ## UI Mockup block

/speckit.plan
  → reads spec.md (now includes wireframe reference)
  → plan.md now lists the wireframe as a visual constraint

/speckit.tasks    → tasks honor layout constraints from wireframe
/speckit.implement → implementation matches signed-off mockup

after_implement hook: "Capture implementation screenshots and compare?" → y
  → captures built UI
  → side-by-side diff vs signed-off wireframe
  → reports visual drift (if any)

What this extension does NOT do

• Orchestration — no queue, no multi-terminal dispatch, no terminal status files. If you want that layer, see TortoiseWolfe/First-Frame, which builds on this extension with a Planner/Generator/Reviewer/Inspector terminal model.
• Style guides — the extension enforces its own canvas and color conventions. If you want different conventions, fork the templates/ directory and publish a preset that overrides them.
• Replace /speckit.constitution — project-wide design standards still belong in the constitution. This extension handles per-feature wireframes.

Prior art

This extension supersedes github/spec-kit#1410, which proposed adding wireframe generation to SpecKit core. That PR predated the extension system (#2130); this extension takes the same ideas into the post-extension-system architecture and extends them with the sign-off binding mechanism and tier-based graceful degradation.

License

MIT — see LICENSE.

Version

• Version: 0.1.0
• Compatible with Spec Kit: >=0.6.0
