spec-kit-FxToNet

This repository packages fx-to-dotnet — a single Spec Kit extension that orchestrates migrating .NET Framework applications to modern .NET (default net10.0) — together with a companion preset and supporting tooling.

The extension integrates tightly with the Spec Kit lifecycle (/speckit.specify → /speckit.plan → /speckit.tasks → /speckit.implement) via five lifecycle hooks. Migration content is owned end-to-end by the extension; user-story implementation is gated behind completion of all migration tasks.

Extension version: 0.8.0 (see fx-to-dotnet/extension.yml)
Preset version: 0.8.0 (see fx-to-dotnet/preset.yml)
License: MIT
Author: Microsoft

[!NOTE] A v0.9.0 prerelease is available for early testing. See Preview Release (Prerelease) at the bottom of this document for details.

Repository Layout

graph LR
    Root[spec-kit-FxToNet]
    Root --> Ext[fx-to-dotnet/<br/>extension + preset]
    Root --> Docs[docs/<br/>plans + integration]
    Root --> Sup[support_scripts/<br/>build + release tooling]

    Ext --> Cmds[commands/<br/>12 core + 5 hooks]
    Ext --> Pol[policies/<br/>migration guidance]
    Ext --> Scr[scripts/<br/>bash + powershell]
    Ext --> Manifest[extension.yml]
    Ext --> PreManifest[preset.yml]
    Ext --> Tpl[templates/<br/>tasks + implement + plan-template]

    style Root fill:#4a9eff,color:#fff
    style Ext fill:#6cc644,color:#fff

Path	Purpose
fx-to-dotnet/	The Spec Kit extension itself — commands, hooks, policies, scripts — plus the companion `fx-to-dotnet-sdd` preset (manifest at fx-to-dotnet/preset.yml, templates under fx-to-dotnet/templates/)
docs/	Design plans: workflow, publish, release pipeline, automated tests, tight-integration plan + tasks
support_scripts/	Cross-platform helpers for version bumping, packaging, deploying, catalog generation, and cross-reference auditing

Quick Start

# 1. Install the extension into your Spec Kit project (stable v0.8.0)
specify extension add fx-to-dotnet
#    To try v0.9.0 instead, see "Preview Release (Prerelease)" at the bottom.

# 2. (Optional) Install the companion preset for deterministic core overrides
specify preset add fx-to-dotnet-sdd

# 3. Drive a full migration via the standard Spec Kit lifecycle.
#    Each step fires a fx-to-dotnet hook (see "End-to-End Lifecycle" below).
/speckit.specify  "Migrate MySolution.sln to net10.0"
                             # after_specify    → speckit.fx-to-dotnet.specify-hook    (detect Framework projects, annotate spec.md)
/speckit.plan                # after_plan       → speckit.fx-to-dotnet.plan-hook       (run assess + plan; write analysis.md + plan.md)
/speckit.tasks               # after_tasks      → speckit.fx-to-dotnet.tasks-hook      (emit [MIG-*] rows with dispatch: trailers)
/speckit.implement           # before_implement → speckit.fx-to-dotnet.implement-hook  THE GATE — run every [MIG-*] before [US*]
                             # after_implement  → speckit.fx-to-dotnet.verify-hook     (optional: solution build verification + completion.md)

Or invoke the orchestrator directly (no lifecycle hooks):

speckit.fx-to-dotnet.orchestrate path/to/MySolution.sln net10.0

End-to-End Lifecycle (with Hooks)

The extension defines five hooks. The before_implement hook is the gate: it refuses to let speckit.implement run user-story tasks until every [MIG-*] task has been executed, skipped, or aborted.

sequenceDiagram
    autonumber
    participant U as User
    participant Core as Spec Kit Core
    participant Hooks as fx-to-dotnet hooks
    participant Cmds as fx-to-dotnet commands

    U->>Core: /speckit.specify
    Core->>Hooks: after_specify → specify-hook
    Hooks->>Hooks: detect Framework projects
    Hooks-->>Core: annotate spec.md (## Migration Context Detected)

    U->>Core: /speckit.plan
    Core->>Hooks: after_plan → plan-hook
    Hooks->>Cmds: assess + plan
    Cmds-->>Hooks: analysis.md, plan.md (in {featureDir}/migration/)
    Hooks-->>Core: annotate plan.md (## .NET Migration Plan)

    U->>Core: /speckit.tasks
    Core->>Hooks: after_tasks → tasks-hook
    Hooks-->>Core: emit [MIG-*] rows with dispatch: trailers

    U->>Core: /speckit.implement
    Core->>Hooks: before_implement → implement-hook (THE GATE)
    Hooks->>Hooks: verify preconditions (analysis.md, plan.md, MIG rows)
    loop per [MIG-*] task
        Hooks->>U: preview + (approve | skip | abort | autoApprove-rest)
        Hooks->>Cmds: dispatch speckit.fx-to-dotnet.<cmd>(args)
        Cmds-->>Hooks: result + build status
    end
    Hooks-->>Core: ✓ Migration Complete — proceed with [US*] tasks
    Core->>Hooks: after_implement → verify-hook (optional)
    Hooks-->>U: solution build verification + completion.md

Hook Summary

Event	Hook	Optional?	Role
`after_specify`	`specify-hook`	no	Detect Framework projects; annotate `spec.md`
`after_plan`	`plan-hook`	no	Run `assess` + `plan`; produce `analysis.md` + `plan.md`; annotate `plan.md`
`after_tasks`	`tasks-hook`	no	Insert `## Phase N: .NET Framework Migration`; emit `[MIG-*]` rows with `dispatch:` trailers
`before_implement`	`implement-hook`	no — THE GATE	Verify preconditions; per-task review of every `[MIG-*]`; validate `^speckit\.fx-to-dotnet\.` namespace
`after_implement`	`verify-hook`	yes	Solution build verification; write `completion.md`

All mandatory hooks silent-exit success on non-Framework workspaces, so they never block ordinary (non-migration) Spec Kit usage.

7-Phase Migration Flow

Whether driven by the lifecycle hooks or by speckit.fx-to-dotnet.orchestrate directly, the migration always follows the same seven phases:

graph TD
    A[orchestrate / implement-hook] --> P1[Phase 1: Assessment]
    P1 --> P2[Phase 2: Planning]
    P2 --> P3[Phase 3: SDK Conversion<br/>layer-by-layer]
    P3 --> P4[Phase 4: Package Compatibility]
    P4 --> P5[Phase 5: Multitarget Migration<br/>layer-by-layer]
    P5 --> P6[Phase 6: ASP.NET Web Migration]
    P6 --> P7[Phase 7: Completion / Deferred]

    P1 -.runs.-> CAssess[assess]
    CAssess -.uses.-> CDetect[detect]
    P2 -.runs.-> CPlan[plan]
    P3 -.runs.-> CConv[convert]
    CConv -.delegates.-> CFix[fix]
    P4 -.runs.-> CPkg[update-packages]
    CPkg -.delegates.-> CFix
    P5 -.runs.-> CMulti[multitarget-migrate]
    CMulti -.delegates.-> CFix
    P6 -.runs.-> CWeb[web-migrate]
    CWeb -.uses.-> CInv[inventory]
    CWeb -.delegates.-> CFix

    style A fill:#4a9eff,color:#fff
    style P1 fill:#1976d2,color:#fff
    style P2 fill:#1976d2,color:#fff
    style P3 fill:#1976d2,color:#fff
    style P4 fill:#1976d2,color:#fff
    style P5 fill:#1976d2,color:#fff
    style P6 fill:#1976d2,color:#fff
    style P7 fill:#388e3c,color:#fff
    style CFix fill:#f9a825
    style CDetect fill:#9c27b0,color:#fff
    style CInv fill:#9c27b0,color:#fff

Layer-by-layer phases (3 and 5) process projects in dependency order: Layer 1 (leaves) first, then Layer 2, etc. Projects within a layer are independent and may run in parallel. Each layer ends in a checkpoint prompt unless alwaysContinue: true is recorded in preferences.md.

State Files (per feature)

As of v0.7.0, all migration artifacts live under the active Spec Kit feature folder at specs/<branch>/migration/. Each feature branch gets its own isolated migration state, and core Spec Kit (/speckit.analyze, /speckit.verify) discovers shared artifacts by convention.

graph TD
    F[specs/&lt;branch&gt;/]
    F --> Spec[spec.md]
    F --> Plan[plan.md]
    F --> Tasks[tasks.md]
    F --> Mig[migration/]

    Mig --> Shared[Shared artifacts]
    Mig --> Priv[Private extension state]

    Shared --> A[analysis.md<br/>assess output]
    Shared --> PL[plan.md<br/>plan output]
    Shared --> O[orchestration.md<br/>phase tracking]

    Priv --> PU[package-updates.md]
    Priv --> Pref[preferences.md]
    Priv --> Det[detection.md]
    Priv --> IS[implement-state.md]
    Priv --> Comp[completion.md]
    Priv --> Proj[&#123;ProjectName&#125;.md<br/>per-project sections]

    style Shared fill:#6cc644,color:#fff
    style Priv fill:#f9a825

Per-project state files ({ProjectName}.md) contain four sections written by different commands: ## SDK Conversion (convert) · ## Build Fix (fix, transient) · ## Multitarget (multitarget-migrate) · ## Web Migration (web-migrate).

Commands Catalog

The extension provides 12 core commands and 5 lifecycle hooks. See fx-to-dotnet/README.md for full details.

Group	Command(s)
Orchestration	`orchestrate`, `initialize`
Phase commands	`assess`, `plan`, `convert`, `update-packages`, `multitarget-migrate`, `web-migrate`
Cross-cutting	`fix` (build/fix loop)
Utilities	`detect`, `inventory`, `show-policy`
Hooks	`specify-hook`, `plan-hook`, `tasks-hook`, `implement-hook`, `verify-hook`

`[MIG-*]` Dispatch Format and Validation

The after_tasks hook emits one row per granular dispatch unit. Each row carries a machine-readable dispatch: trailer that the before_implement hook parses and validates.

- [ ] [MIG-001] [P0] Convert ProjectA.csproj to SDK-style — dispatch: speckit.fx-to-dotnet.convert(ProjectA.csproj)
- [ ] [MIG-002] [P0] Apply package chunk 1 to LibraryA (3 minor updates) — dispatch: speckit.fx-to-dotnet.update-packages(project=src/LibraryA/LibraryA.csproj, chunk=1)
- [ ] [MIG-003] [P0] Multitarget LibraryA to net10.0       — dispatch: speckit.fx-to-dotnet.multitarget-migrate(LibraryA.csproj)
- [ ] [MIG-004] [P0] Web migrate WebApp slice=bootstrap    — dispatch: speckit.fx-to-dotnet.web-migrate(WebApp.csproj, slice=bootstrap)

flowchart TD
    Start([before_implement hook starts]) --> Pre{Preconditions met?<br/>analysis.md + plan.md + MIG rows}
    Pre -- no --> Fail[Exit non-zero<br/>print remediation]
    Pre -- yes --> Loop{Next unchecked<br/>&#91;MIG-*&#93;?}
    Loop -- none --> Done[Append ## Migration Execution Summary<br/>insert ✓ Migration Complete<br/>allow speckit.implement]
    Loop -- yes --> Validate{dispatch: matches<br/>^speckit\.fx-to-dotnet\.?}
    Validate -- no --> Reject[Mark &#91;~&#93;<br/>audit: dispatch-rejected]
    Reject --> Loop
    Validate -- yes --> Ask{User choice}
    Ask -- approve --> Run[Invoke dispatch target]
    Ask -- skip --> Skip[Mark &#91;~&#93;]
    Ask -- abort --> Halt([Halt — leave rows unchecked])
    Ask -- autoApprove-rest --> Run
    Run --> Build{Build OK?}
    Build -- yes --> Mark[Mark &#91;X&#93;]
    Build -- no --> PauseReview[ALWAYS pause for review<br/>even under autoApprove-rest]
    PauseReview --> Ask
    Mark --> Loop
    Skip --> Loop

    style Fail fill:#d32f2f,color:#fff
    style Reject fill:#d32f2f,color:#fff
    style Done fill:#388e3c,color:#fff
    style PauseReview fill:#f9a825

The ^speckit\.fx-to-dotnet\. prefix check is the technical enforcement that migrations only run extension-owned commands. Targets that fail this check are rejected with a dispatch-rejected audit-log entry.

Prerequisites

Spec Kit ≥ 0.1.0 (extension); ≥ 0.7.2 (preset and workflows)
.NET SDK (for dotnet build via the fix command)
MCP Servers:
- Microsoft.GitHubCopilot.Modernization.Mcp — project analysis and SDK-style conversion (required by assess and convert)

Sample .mcp.json:

{
  "servers": {
    "Microsoft.GitHubCopilot.Modernization.Mcp": {
      "type": "stdio",
      "command": "dotnet",
      "args": ["run", "--project", "<path-to-appmod-mcp-server>"]
    }
  }
}

Standalone Usage

Several commands work independently of the full migration suite:

speckit.fx-to-dotnet.fix — iteratively build and fix compilation errors in any .NET project
speckit.fx-to-dotnet.detect — classify any .NET project (SDK-style, web host, service, library, etc.)
speckit.fx-to-dotnet.inventory — extract endpoint inventory from any legacy ASP.NET web project
speckit.fx-to-dotnet.show-policy — view a named migration policy document

Documentation

fx-to-dotnet extension README — extension-level details, commands, hooks, state files (also covers the bundled fx-to-dotnet-sdd preset)
docs/speckit-tight-integration-plan.md — the integration design plan
docs/release-pipeline-plan.md — release pipeline
docs/publish-plan.md — publishing plan
docs/automated-test-plan.md — automated test plan

Preview Release (Prerelease)

v0.9.0 is available as a prerelease. It is cut from the migrate-spec branch and is not the latest stable release (v0.8.0). Use it to try the upcoming features; expect breaking changes before it is promoted to a stable release.

The v0.9.0 preview advances both the extension and the companion preset to 0.9.0 and focuses on MCP-driven analysis and tighter Spec Kit integration:

MCP preflight gate — a new speckit.fx-to-dotnet.mcp-preflight command plus connectivity-check scripts verify the Microsoft.GitHubCopilot.Modernization.Mcp server is reachable before a migration starts.
Transitive dependency closure — paired get-transitive-dependency-closure scripts compute the full dependency graph to drive layer-by-layer SDK conversion and cross-project version alignment.
New policies — conditional-compilation and cross-project-version-alignment; mcp-setup is restructured into a standard policy folder (policies/mcp-setup/POLICY.md).
Tighter lifecycle integration — preset overrides now include specify and plan templates, enabling a specify-driven flow where migration context is captured up front.
Multitarget improvements — refined speckit.fx-to-dotnet.multitarget-migrate handling and cross-project version reconciliation.

Try the prerelease

There are three ways to run v0.9.0. Option A is recommended for most users.

Option A — Install the published release asset (recommended)

The v0.9.0 release attaches a packaged fx-to-dotnet.zip plus SHA256SUMS.txt:

# 1. Download the packaged extension + checksum from the v0.9.0 prerelease
curl -LO https://github.com/RogerBestMsft/spec-kit-FxToNet/releases/download/v0.9.0/fx-to-dotnet.zip
curl -LO https://github.com/RogerBestMsft/spec-kit-FxToNet/releases/download/v0.9.0/SHA256SUMS.txt

# 2. Verify the download
sha256sum -c SHA256SUMS.txt

# 3. Extract — the zip contains a single top-level fx-to-dotnet/ folder
unzip fx-to-dotnet.zip

# 4. Install the extracted folder (the bundle ships both the extension and the preset)
specify extension add --dev ./fx-to-dotnet
specify preset add --dev ./fx-to-dotnet

Option B — Windows PowerShell

Same as Option A, using Invoke-WebRequest and Expand-Archive for the download and extract steps:

Invoke-WebRequest https://github.com/RogerBestMsft/spec-kit-FxToNet/releases/download/v0.9.0/fx-to-dotnet.zip -OutFile fx-to-dotnet.zip
Expand-Archive fx-to-dotnet.zip -DestinationPath .
specify extension add --dev .\fx-to-dotnet
specify preset add --dev .\fx-to-dotnet

Option C — Track the branch directly

Clone the migrate-spec branch and install from the checkout (useful for following ongoing changes):

git clone --branch migrate-spec https://github.com/RogerBestMsft/spec-kit-FxToNet.git
specify extension add --dev ./spec-kit-FxToNet/fx-to-dotnet
specify preset add --dev ./spec-kit-FxToNet/fx-to-dotnet

Once v0.9.0 is promoted to a stable release, the version bullets near the top of this document will be updated and this section will be removed. See the CHANGELOG and the releases page for the full history.

License

MIT — see LICENSE.

fx-to-dotnet

spec-kit-FxToNet

Repository Layout

Quick Start

End-to-End Lifecycle (with Hooks)

Hook Summary

7-Phase Migration Flow

State Files (per feature)

Commands Catalog

`[MIG-*]` Dispatch Format and Validation

Prerequisites

Standalone Usage

Documentation

Preview Release (Prerelease)

Try the prerelease

Option A — Install the published release asset (recommended)

Option B — Windows PowerShell

Option C — Track the branch directly

License

Stats

Version

Install

Links

Owners

License

fx-to-dotnet

spec-kit-FxToNet

Repository Layout

Quick Start

End-to-End Lifecycle (with Hooks)

Hook Summary

7-Phase Migration Flow

State Files (per feature)

Commands Catalog

[MIG-*] Dispatch Format and Validation

Prerequisites

Standalone Usage

Documentation

Preview Release (Prerelease)

Try the prerelease

Option A — Install the published release asset (recommended)

Option B — Windows PowerShell

Option C — Track the branch directly

License

Stats

Version

Install

Links

Owners

License

`[MIG-*]` Dispatch Format and Validation
